순간유량계[RMA,RMB,RMC] |
|
구 분 : Specifications
- Meter Body Bezel and Tube : Polycarbonate
- Wetted Metal Parts : Stainless Steel
- Floats : St.Steel. Blk Glass.Alum,K Monel.Tung .Carbide
- Float Stops : Polycarbonate
- Pipe Connections : RMA.1/8". / RMB 1/4" / RMC 1/2" NPT
- "O" Rings : Neoprene and Buna N
- Fittings : Stainless Steel Brazed to Stainless Steel
- Rivets : Stainless Steel. set into slots
- scale : Brushed Alyuminum -Clear Epoxy Coated
- Knobs : Abs Plastic
- Pressure Limits : RMA (6.9 bar) RMB(4.8 bar)RMC(2.4bar) max
- Temperature Limits : 130 F maximun
- Sccuracy : RAM . 4% . RMB 3% RMC 2% full scale
- Weight : RMA (113.4g)RMB(368.54g)RMC(1105.63g)
- Metering Valve : Stainless Steel(rma,rmb,rmc)
|
|
|
|
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
)
